HEIDENHAIN’s linear measuring systems eliminate a number of potential sources of error such as reversal blur, pitch error or ball screw temperature expansion. No matter how high the demands are on positional accuracy and the speed of machining, linear measuring systems are paramount.
The linear encoders are available as either closed or open systems, which in turn support the countless possibilities for precision measurement with HEIDENHAIN & NORDIC!
We are ready at NORDIC A/S to help you!
HEIDENHAIN linear measuring systems are available in the following lengths:
0 – 499 mm
50, 70, 100, 120, 140, 150, 170, 180, 190, 200, 220, 240, 250, 270, 300, 320, 340, 350, 370, 400, 420, 440, 450, 470
500 – 999 mm
500, 520, 540, 550, 570, 600, 620, 640, 650, 670, 700, 720, 740, 750, 770, 800, 820, 840, 850, 870, 900, 920, 940, 950, 970
1000 – 1499 mm
1000, 1020, 1040, 1050, 1070, 1120, 1140, 1180, 1220, 1240, 1320, 1340, 1420, 1440
1500 – 1999 mm
1520, 1540, 1620, 1640, 1720, 1740, 1820, 1840
2000 – 2999 mm
2020, 2040, 2240, 2440, 2640, 2840
3000 – 72040 mm
3040, 3240, 3440, 3640, 3840, 4040, 4240 … 72040e
HEIDENHAIN linear measuring systems are available with the following absolute interfaces:
HEIDENHAIN linear measuring systems are available with the following incremental interfaces:
TTL Interpolation
TTLx1
TTLx5
TTLx10
TTLx20
TTLx32
TTLx50
TTLx100
The team behind NORDIC A/S has extensive experience in designing, supporting and repairing measurement systems for many different industries.
We help with everything from simple measuring systems on manual machine tools, to specially designed vibration sensors that, for example, measure the weight of the vehicles crossing a bridge.
Supported by HEIDENHAIN’s huge selection of encoders and accessories, all tasks can be solved!
